Beleuchtungen Diffuse direkte Auflichtbeleuchtung FLFQ-Si245x200-C90-IR24

FLFQ-Si245x200-C90-IR24

Artikel-Nr.: 6-7-200245-55

LED High Brightness Diffuse Front Light - High Power SMD LEDs rectangle shaped Front Light with aperture for camera

6-7-200245-55 FLFQ-Si245x200-C90-IR24 LED High Brightness Diffuse Front Light - High Power SMD LEDs rectangle shaped Front Light with aperture for camera 1 FLFQ-Si245x200-C90.svg IR (850 nm) ir.svg 24 14.4

Technische Daten
Lichtfarbe/Wellenlänge IR (850 nm)
Stromstärke 0.6 A
Leistung 14.4 W
Spannung 24 V
Illumination
Operating Voltage: 24 V
Current: 0.6 A
Power Consumption: 14.4 W
Voltage: Continuous = 24V Pulsing 48V 0-10% Duty Cycle
Ripple Voltage: ≤ Vs ±5% V
Eye safety: Exempt Group
IP Rating: IP 50
Connector: JST SMR-03V
Connector Pin: Pin 1: + Pin 2: no connection Pin 3: -
Reverse Battery Protection: yes
Mechanical
Housing: Aluminium
Cable: 600 mm
Weight: 2200g
LED
LED Color: IR (850 nm)
LED Package: SMD
LED Life Span Strobe: Est. >50,000 hours (drop to 50% intensity at 25°C ambient temperature)
LED Life Span Continous: 20,000 hours
Number of LED
Total Number of LED: 360 LED(s)
Usage
Operating Condition: Temp 0-35 °C, Humidity 20-85%
Operating Temperature: Approx. 32 °C
Cooling Method: Attached to large machine part
Working Distance: 20-200 mm
Produktbild FLFQ-Si245x200-C90-IR24
Kabel/Stecker Konfigurator
Wir liefern standardmäßig ein Kabel mit ca. 30-50 cm Länge und einem JST Stecker. Die genaue Abmessung finden Sie in unserer Zeichnung.

Beispiele | Anwendungsbilder

Stecker

JST Male (Standard)
JST Female
Offenes Kabelende
M8 3-polig Male
M8 3-polig Female
M8 4-polig Male
M8 4-polig Female
M12 4-polig Male
M12 4-polig Female
M12 5-polig Male
M12 5-polig Female

Weiteres Zubehör

Wir bieten Ihnen umfangreiches Zubehör.
Weitere Informationen finden Sie unter Polfilter oder Adapter.
